The DVE combines economy and ease of operation with traditional Brookfield excellence to provide reliable viscosity readings. Easy to use interface allows operators to change test parameters easily and test like a pro no time! The digital display ensures easy and accurate readout of test results for simultaneous measurement of viscosity and torque. Quality of manufacture guarantees reliable performance and long life.
FEATURES & BENEFITS
TORQUE EXPLANATIONS:
HELP ME CHOOSE
Having difficulties determining what instrument is best for you? Try our section for guidance on the model selection process, spindle construction considerations, and other useful information to help you make an informed decision on the best instrument for your application.
VISCOSITY RANGE cP (mPa•s) |
SPEEDS | |||
MODEL | Min. | Max. | RPM | Number of Increments |
LVDV-E | 1† | 2M | 0.3-100 | 18 |
RVDV-E | 100†† | 13M | 0.3-100 | 18 |
HADV-E | 200†† | 26M | 0.3-100 | 18 |
HBDV-E | 800†† | 104M | 0.3-100 | 18 |
SPRING TORQUE | ||
MODEL | Dyne-cm | Milli Newton-m |
LVDV-E | 673.7 | 0.0673 |
RVDV-E | 7,187.0 | 0.7187 |
HADV-E | 14,374.0 | 1.4374 |
HBDV-E | 57,496.0 | 5.7496 |
Uses | ||
Low Viscosity | Medium Viscosity | High Viscosity |
Adhesives (solvent base) | Adhesives (hot melt) | Asphalt |
Biological Fluids | Ceramic Slurries | Caulking Compounds |
Chemicals | Creams | Epoxies |
Coatings, Water-Based | Gums | Gels |
Inks, Water-Based | Inks (screen printing) | Inks (ballpoint, offset) |
Oils | Paints | Pastes |
Paints, Latex | Paper Coatings and Pulp | Putty |
Photo Resist | Plastisols | Roofing Compounds |
